PP (Polypropylene) Filter Press by Pharmatech
SPECIFICATION
STRUCTURE
CAST IRON / MILD STEEL
SIZES / Nozzle
12" TO 48" / SS 304/PP
CLOSING DEVICE TYPE
MANUAL, RATCHED GEAR, HAND HYDRAULIC AND POWER HYDRAULIC
WORKING PRESSURE
UPTO 7 kg/cm2
FILTER MEDIA
PP/NYLON/ POLYESTER/ COTTON
WORKING TEMP.
UPTO 60 C
overview
Polypropylene (PP)Filter Press by Pharmatech
A PP Filter Press Machine by Pharmatech is a type of filter press by Pharmatech designed to separate solids from liquids. The plates in the machine are made from polypropylene (PP). These plates create chambers where liquid with solid particles is poured in. The machine applies pressure, and the liquid passes through filter cloths, while the solids are left behind, forming a cake.
This machine is widely used in industries because it is reliable, cost-effective, and works well for large amounts of liquid. The PP Filter Press Machine by Pharmatech helps companies remove waste materials from liquids efficiently.
Our Range of PP Filter Press Machine by Pharmatech
12 Inch Manual PP Filter Press Machine by Pharmatech
Get Latest Price
Product BrochureKey Specifications
PP Filter Press Machine by Vasu Pharmatech is a reliable and cost-effective solution for solid–liquid separation and sludge dewatering in wastewater and industrial filtration. Also known as Filter Press or Filter Press Machine by Pharmatech , it delivers efficient filtration and stable performance at low operating cost.
This Filter Press Machine by Pharmatech is made with high-quality PP filter plates and a strong cast iron structure, ensuring long service life, easy manual operation, and low maintenance. It is widely used by Filter Press by Pharmatech Manufacturers in India for consistent filtration results.
- Plate Size: 300 x 300 mm
- Filtration Area: 1.62 m²
- Plate Material: PP (Polypropylene)
- Structure Material: Mild Steel / Cast Iron
- Number of Plates: 12 Plates
- Model Name / Number: VPFP12
- Cake Holding Capacity: 24 L
- Brand: Vasu Pharmatech
- Filter Media Options: PP / Nylon / Polyester / Cotton
- Nozzle Material: SS304 / PP
- Closing Device: Manual / Power Hydraulic
- Available Sizes: 12 to 48 inch
As one of the trusted Filter Press by Pharmatech Manufacturers, Vasu Pharmatech delivers durable and efficient PP Filter Press Machines for wastewater treatment and industrial filtration applications.
24 Inch Manual PP Filter Press Machine by Pharmatech.
Get Latest Price
Product BrochureKey Specifications
PP Filter Press Machine by Vasu Pharmatech is a reliable and cost-effective solution for solid–liquid separation and sludge dewatering in wastewater and industrial filtration. Also known as Filter Press or Filter Press Machine by Pharmatech , it delivers efficient filtration and stable performance at low operating cost.
This Filter Press Machine by Pharmatech is made with high-quality PP filter plates and a strong cast iron structure, ensuring long service life, easy manual operation, and low maintenance. It is widely used by Filter Press by Pharmatech Manufacturers in India for consistent filtration results.
- Plate Size: 600 × 600 mm
- Filtration Area: 20 m²
- Plate Material: PP (Polypropylene)
- Structure Material: Mild Steel / Cast Iron
- Number of Plates: 24 Plates
- Model Number: VPFP24
- Cake Holding Capacity: 290 L
- Filter Media Options: PP / Nylon / Polyester / Cotton
- Nozzle Material: SS304 / PP
- Closing Device: Manual / Power Hydraulic
As one of the trusted Filter Press by Pharmatech Manufacturers, Vasu Pharmatech delivers durable and efficient PP Filter Press Machines for wastewater treatment and industrial filtration applications.
30 Inch Filter Press Machine by Pharmatech.
Get Latest Price
Product BrochureKey Specifications
PP Filter Press Machine by Vasu Pharmatech is a reliable and cost-effective solution for solid–liquid separation and sludge dewatering in wastewater and industrial filtration. Also known as Filter Press or Filter Press Machine by Pharmatech , it delivers efficient filtration and stable performance at low operating cost.
This Filter Press Machine by Pharmatech is made with high-quality PP filter plates and a strong cast iron structure, ensuring long service life, easy manual operation, and low maintenance. It is widely used by Filter Press by Pharmatech Manufacturers in India for consistent filtration results.
- Plate Size: 750 × 750 mm
- Number of Plates: 30 Plates
- Filtration Area: 31.10 m²
- Plate Material: PP (Polypropylene)
- Structure Material: Mild Steel / Cast Iron
- Filter Media: Cotton Cloth
- Brand: Vasu Pharmatech
As one of the trusted Filter Press by Pharmatech Manufacturers, Vasu Pharmatech delivers durable and efficient PP Filter Press Machines for wastewater treatment and industrial filtration applications.
36 Inch Hydraulic Filter Press Machine by Pharmatech.
Get Latest Price
Product BrochureKey Specifications
PP Filter Press Machine by Vasu Pharmatech is a reliable and cost-effective solution for solid–liquid separation and sludge dewatering in wastewater and industrial filtration. Also known as Filter Press or Filter Press Machine by Pharmatech , it delivers efficient filtration and stable performance at low operating cost.
This Filter Press Machine by Pharmatech is made with high-quality PP filter plates and a strong cast iron structure, ensuring long service life, easy manual operation, and low maintenance. It is widely used by Filter Press by Pharmatech Manufacturers in India for consistent filtration results.
- Plate Size: 900 × 900 mm
- Number of Plates: 36 Plates
- Filtration Area: 54.50 m²
- Plate Material: PP (Polypropylene)
- Structure Material: Mild Steel / Cast Iron
- Filter Media: PP Cloth
- Brand: Vasu Pharmatech
As one of the trusted Filter Press by Pharmatech Manufacturers, Vasu Pharmatech delivers durable and efficient PP Filter Press Machines for wastewater treatment and industrial filtration applications.
Working
How Does a PP Filter Press Machine by Pharmatech Work?
The PP Filter Press Machine by Pharmatech works by separating the liquid from the solid material using pressure. Here’s a simple explanation of how it works:
- Filling: The liquid, which contains solid particles, is pumped into the filter press by Pharmatech.
- Filtration: The liquid is forced through a special cloth called a filter cloth, leaving the solids behind in the form of a cake.
- Drying: After the liquid is separated, the solids dry up inside the machine.
- Discharge: The solid cake is then removed, leaving clean liquid behind.
This simple process makes the PP Filter Press Machine by Pharmatech perfect for filtering large volumes of liquid and separating unwanted solids.
Calculator
Filter Press by Pharmatech Sizing Calculator
Ensure Inlet % is less than Cake %.
Results
Total Dry Solids:0 kg/day
Total Daily Cake Volume:0 m³/day
Required Capacity per Cycle:0 Liters
Need Expert Consultation?
Connect with Vasu Pharmatech experts for instant guidance and requirements.
Benefits
Benefits of Using a PP Filter Press Machine by Pharmatech
Using a PP Filter Press Machine by Pharmatech has many benefits:
1. High Efficiency
A PP Filter Press Machine by Pharmatech can filter large amounts of liquid very quickly. This makes it a popular choice in industries where time and efficiency are important.
2. Durable and Strong
The machine’s PP filter plates are made from strong materials that can resist chemicals, heat, and other tough conditions. This means the machine will last a long time, even in harsh environments.
3. Cost-Effective
The PP Filter Press Machine by Pharmatech is an affordable choice for industries because it works efficiently and requires little maintenance. It helps companies save money by reducing waste and using less energy.
4. Eco-Friendly
By using a Filter Press Machine, companies can reduce their environmental impact. The machine filters out waste materials, ensuring that harmful solids don’t get into the environment.
5. Customizable
You can get PP Filter Press Machines in different sizes and designs to meet your specific needs. This flexibility makes the machine suitable for many industries.
Components
PP Filter Press Machine by Pharmatech
- PP Filter Plates: Made from strong, lightweight polypropylene, these plates form the chambers where filtration occurs and resist chemicals.
- Filter Cloth: Traps solid particles while allowing liquid to pass through, ensuring a clean and clear output.
- Hydraulic System: Generates the pressure needed to force liquid through the filter cloth, effectively separating solids from liquids.
- Control Panel: Lets users control the pressure and filtration speed, allowing for adjustments to optimize performance.
testimonials
What Our Clients Say About Us
5/5
PP Filter Press
Vasu’s PP Filter Press gave us consistent output with zero downtime. Quality is better than other vendors.
Sanjay Patel
Ahmedabad
5/5
MBBR Media
We switched to Vasu’s MBBR Media in our ETP plant. Biofilm grew faster and media remained stable under load.
Neeraj Saini
Bhopal
5/5
Tube Deck Media
Tube Deck Media from Vasu reduced our settling time and sludge issues. Good performance in compact STPs.
Pooja Trivedi
Jaipur
5/5
Coarse Bubble Diffuser
Coarse Bubble Diffuser gave even air distribution. Setup was quick and it’s been running well for over a year.
Manish Goyal
Nashik
5/5
Fine Bubble Diffusers
We installed Fine Disc Diffusers in our plant. Noticed better oxygen levels and lower energy use immediately.
Anisha Roy
Kolkata
5/5
Tube Settler Media
We trust Vasu for Tube Settler Media. The material quality is great and works efficiently even in high TSS.
Nisha Bhandari
Udaipur
5/5
PP Filter Press
We’ve been using PP Filter Press from Vasu for 2+ years. Strong build, smooth performance, and zero leakage issues.
Ramesh Verma
Vadodara
5/5
MBBR Media
Vasu’s MBBR Media helped improve our STP output quickly. No clogging, fast biofilm growth, and great durability.
Ankit Sharma
Pune
5/5
Tube Deck Media
After installing their Tube Deck Media, settling improved instantly. Easy to handle and works well in clarifiers.
Meena Desai
Indore
Application
Applications of PP Filter Press Machines by Pharmatech
-
Wastewater Treatment: The PP Filter Press Machine by Pharmatech effectively filters solid waste from water, ensuring clean water is produced and harmful solids are removed.
-
Food and Beverage Industry: In this industry, the PP Filter Press Machine by Pharmatech
filters liquids like juices and wine, removing unwanted particles for a pure product.
-
Chemical Processing: The machine separates valuable chemicals from waste, improving efficiency and reducing costs in chemical processing.
-
Pharmaceuticals: It filters impurities in the pharmaceutical industry, ensuring products are clean and safe for consumption.
Conclusion
A PP Filter Press Machine from Vasu Pharmatech is an essential tool for industries needing to separate solids from liquids efficiently. Whether you’re in wastewater treatment, food processing, or chemical manufacturing, our PP Filter Press Machine by Pharmatech can streamline your processes, making them faster, more efficient, and environmentally friendly.
As one of the leading Filter Press Manufacturers by Pharmatech in India, Vasu Pharmatech provides high-quality machines tailored to your specific needs. Our machines are durable, cost-effective, and designed to filter large volumes of liquid while effectively removing unwanted solids.
Investing in a PP Filter Press Machine from Vasu Pharmatech is a smart choice for a reliable filtration solution. Our machines will help your business operate smoothly, reduce waste, and ensure clean output in all your processes. Choose Vasu Pharmatech for quality and efficiency in filtration!
Frequently Asked Question
FAQ
A Filter Press Machine by Pharmatech works by pumping a liquid with solid particles into chambers where the liquid is pushed through filter cloths. The solids stay behind, forming a filter cake, and the clean liquid passes through.
PP (polypropylene) plates are used because they are strong, lightweight, and resistant to chemicals. This makes them perfect for long-term use in demanding environments.
Yes, most filter press by Pharmatech manufacturers offer customization options to meet your specific industrial needs.
